1

Standard NC control system

Taiwan New Generation

2

Maximum processing diameter

?12mm

3

Maximum machining length (1 time clamping)

310mm

4

Maximum stroke without guide bush

60mm

5

Maximum drilling diameter of positive spindle end face

?11mm

6

Maximum drilling depth of positive spindle end face

50mm

7

Spindle through-hole diameter

?13mm

8

Spindle rotation speed

6000rpm

9

Maximum tool diameter for rotary tools

?11mm

10

Maximum rotating tool speed

5500rpm

11

Back spindle maximum collet diameter

?12mm

12

Maximum drilling diameter of back spindle end face

?11mm

13

Back spindle rotation speed

6000rpm

14

Number of tool mounting

20

15

Row Tool Turning Tools

7

16

Side rotation tool

5

17

Frontal drilling tools

4

16

Backside drilling tools

4

Serial number

Tool size

17

Tools (turning tools)

?12mm*6+?16mm*1

18

Collet, guide bush

19

Spindle collet

STAR12

20

guide sleeve

STAR12

21

Back spindle collet

STAR12

22

Side rotating tool chuck

ER16*3+ER20*2

23

Collets for drilling collets

ER16

Serial number

Rapid feed rate

24

X1 Y 1 Z1 Z2

30m/min

Serial number

Motor

26

Spindle motor

2kw

27

Rotary tool motor

2.9kw

28

Axial Motor

750kw

29

Center height

1050mm

30

Power supply capacity

10KVA

31

Pneumatic device Required air pressure

0.6MPa

32

Machine weight

2000Kg

33

Machine external dimensions (L*W*H)

275*166*193cm

34

Mailbox volume

155L
